Additive thermomechanical simulation

Aibuild FETS is finite element thermomechanical simulation software for metal and large format additive manufacturing, up to 10,000× faster than existing solutions. It predicts temperature, distortion and residual stress for DED, WAAM, FGF, FDM and AFSD builds, works with any CAM software, and is validated by the US aerospace research institute NIAR.

What does Aibuild FETS predict?

FETS runs a layer-by-layer thermomechanical simulation of the build and presents the results across six views. The report also recommends a wait time for each layer, calculated from that layer’s own cooling profile. Applying those in your CAM software replaces a single blanket dwell time, which can stretch a large build by hours without making it safer.

  1. 01

    Temperature.

    The thermal distribution at any point during the build.

  2. 02

    Stress.

    Von Mises stress through the part and substrate.

  3. 03

    Displacement.

    Predicted distortion and warpage, so you can check you have enough stock left for machining.

  4. 04

    Interlayer bonding.

    Regions where interpass temperature falls outside your material’s range, flagging slumping when it’s too hot and poor adhesion when it’s too cold.

  5. 05

    Crack risk.

    Regions where stress approaches the material’s ultimate tensile strength.

  6. 06

    Summary.

    The key findings and inputs in one place, exportable as a PDF report to share with your team.

Built for DED, WAAM, FGF, FDM, AFSD.

Aibuild FETS supports the full range of large format and metal additive manufacturing processes across DED, WAAM, AFSD, FGF and FFF, covering both metals and thermoplastics. It is CAM agnostic, works with your existing toolpaths, runs on standard hardware and requires no specialist setup or onboarding.

CAM agnostic.

Import your gcode to start a simulation. You’re not forced to migrate your data to a new CAM platform.

No accuracy trade-off.

Speed without compromise. Replicating physics, validated by US aerospace.

Runs on NVIDIA GPU.

No additional high powered workstation required. Aibuild FETS is engineered to be lean.

World’s fastest FE simulation.

Minimum 100× faster than any competing solution for DED and LFAM processes.

Easy to calibrate & use.

Designed so your team can get results quickly, not after weeks of specialist training.

Iterate like never before.

Compare scenarios quantitatively in minutes not hours or days. Make better decisions, faster.

Runs on your laptop. No HPC.

Most process simulation tools were built for powder bed fusion and run on the CPU. For a large DED or WAAM part with a million elements and a print lasting a day or more, a single run can take many hours, sometimes days, and usually needs dedicated HPC hardware and an FEA specialist to set it up.

FETS was written from scratch to run on the GPU. Instead of working through elements one at a time on the CPU, it solves the whole finite element problem in parallel across thousands of GPU cores. That is why it runs on a laptop and why there is nothing to install on a cluster.

Aibuild FETS simulation setup on a laptop GPU

Works with your CAM.

Import your G-code from any CAM software that exports Marlin G-code, including Siemens NX, Fusion and most dedicated additive toolpath software. Aibuild CAM is not required.

Marlin G-code.

Import from Siemens NX, Fusion and most dedicated additive toolpath software.

Planar and non-planar.

Planar and non-planar toolpaths both work, so robotic and multi-axis builds are covered.

Custom substrate.

Import a custom substrate if you’re building onto a curved or pre-machined part.

Material presets.

316L stainless steel, Ti-6Al-4V, Inconel 718, AlSi10Mg, PLA or ABS-CF, or enter your own properties.

Clamping and quality.

Pick which edges are clamped, set the simulation quality, and run.

Gantry and robotic.

DED (laser wire and laser powder), WAAM, AFSD, FGF and FFF, on gantry and robotic systems.

NIAR

Validated by NIAR.

As a research institute serving the aerospace industry, NIAR's mission is to validate and de-risk advanced manufacturing technologies before they reach production floors. Thermal control has been one of the biggest challenges holding back metal additive at industrial scale. When we validated Aibuild's FETS, what stood out was the GPU acceleration with NVIDIA's CUDA. It made complex finite element thermal simulation fast enough to actually use in production workflows, not just as a research tool. This foundation means we're well positioned to benefit from the next step: ultra-fast physics AI simulation using NVIDIA's PhysicsNeMo framework, which Aibuild is developing to deliver speeds an order of magnitude faster than today. For the aerospace manufacturers we work with, this represents a validated path forward: they can adopt large-format metal AM with the thermal process control they need today, and benefit from AI-accelerated simulation speeds as that technology matures.
NIARJeswin J. ChankaramangalamProgramme Director, NIAR

Inside Aibuild FETS.

Aibuild FETS Process results screen
Process resultsSwitch between temperature, displacement and stress on the same run.
Aibuild FETS Optimise screen
OptimiseSet goals for temperature, stress, distortion and build time; FETS searches the rest.
Aibuild FETS Projects screen
ProjectsEvery part you’ve simulated, with every iteration you’ve run against it.
Aibuild FETS Results screen
ResultsVon Mises stress across the build, with a deformation scale and playback.
Aibuild FETS Materials library screen
Materials libraryThermal and mechanical properties, constant or temperature-dependent.
99%
Independently validated

Aibuild FETS achieved 99% accuracy on a WAAM weave wall.

This validation was performed as part of COMPADDITIVE, a research project funded by an Innovate UK grant, in collaboration with Additure, AMRC and Turkish Aerospace Industries.

Your data stays on your machine.

FETS runs entirely offline. Your G-code, material data and results stay on your own hardware, and nothing is sent to Aibuild. For aerospace and defence programmes that can’t put part geometry into a cloud tool, that removes a whole approval conversation.

Developed by engineers, for engineers.

Aibuild FETS is CAM agnostic and requires no specialist computers. It integrates directly into your existing workflows across a wide range of manufacturing environments. Plus the easy calibration means teams are up and running quickly, without lengthy onboarding or specialist training.

FAQs

Aibuild FETS is finite element simulation software built specifically for large format and metal additive manufacturing. It delivers thermal, thermomechanical, distortion and residual stress simulation up to 10,000 times faster than existing FEA solutions, returning results in seconds to minutes on standard hardware without requiring specialist equipment or dedicated FEA expertise.

Unlike traditional simulation tools that operate outside the manufacturing workflow, Aibuild FETS is CAM agnostic and integrates directly into existing toolpath and process workflows. It is powered by NVIDIA CUDA-X GPU acceleration and has been independently validated by NIAR, the National Institute for Aviation Research.

For engineering teams working with DED, WAAM, FGF, FDM and AFSD processes, Aibuild FETS makes it possible to predict build outcomes, catch failure risks and iterate on process parameters before a single layer is deposited.

Standard FEA thermal solvers were not built for additive manufacturing. They require manual mesh reconstruction every time a toolpath changes, operate outside the CAM environment as a separate tool in a separate workflow, demand significant HPC hardware investment often exceeding one million dollars and return results after hours or days of compute time. For engineering teams running iterative process development on DED or WAAM builds, that speed and friction makes routine simulation impractical.

Aibuild FETS is different in every one of those areas.

It is built natively for additive manufacturing processes, meaning toolpath changes flow directly into simulation without manual reconstruction. It integrates into the existing CAM workflow without requiring a platform switch.

It runs on standard hardware without specialist infrastructure. And it returns thermal, thermomechanical, distortion and residual stress results up to 10,000 times faster than conventional FEA tools, in seconds to minutes rather than hours or days.

Critically, that speed does not come at the cost of accuracy. Aibuild FETS has been independently validated by NIAR, the National Institute for Aviation Research, achieving 96.8% mean prediction accuracy on real stainless steel 17-4PH Wire Arc DED builds. The accuracy is equivalent to high fidelity FEA. The speed is in a different category entirely.

Aibuild FETS supports today’s most widely used additive manufacturing processes including Directed Energy Deposition (DED), Wire Arc Additive Manufacturing (WAAM), Additive Friction Stir Deposition (AFSD), Fused Granulate Fabrication (FGF), and Fused Filament Fabrication (FFF), covering both metals and thermoplastics.

Simulation outputs cover thermal analysis, thermomechanical behaviour, distortion prediction and residual stress distribution, giving engineering teams a complete picture of build performance before printing begins.

Because Aibuild FETS is CAM agnostic, it works with toolpaths generated by any CAM platform and requires no changes to existing software or hardware setups. Engineers working across robotic and gantry systems with metals including steel and titanium alloys, as well as high performance thermoplastics, can integrate Aibuild FETS directly into their current workflow without disruption.

Aibuild CAM thermal analysis is optimised for speed. It produces a temperature envelope in minutes and is ideal for low-conductivity materials (e.g. carbon-fibre-reinforced polymers) or early-stage concept validation. Its simplifying assumptions limit accuracy on dense or high-conductivity geometries.

Aibuild FETS gives you full finite element simulation across thermal, thermomechanical, distortion and residual stress outputs. It models the complete physics of the build including the path the tool takes, the thermal history at every layer, mechanical response, stress accumulation and distortion across the full geometry. This level of fidelity matters most for dense or high-conductivity materials like steel and titanium alloys, complex geometries, and any application where a simplified thermal estimate is not sufficient to validate the build with confidence.

CAM thermal analysis makes simplifying assumptions that work well in certain material and geometry contexts. FETS applies full finite element rigour validated by NIAR to 96.8% mean prediction accuracy, making it the right tool when the build is complex, the material is demanding, or the cost of getting it wrong is high.

Large format additive manufacturing processes including DED, WAAM, FGF, FDM and AFSD are highly sensitive to thermal conditions during deposition. Interpass temperature, heat accumulation, cooling rates and thermal gradients all directly affect material properties, dimensional accuracy and build integrity. Aibuild FETS delivers full thermal simulation for large format additive manufacturing in seconds, on standard hardware, integrated directly into the existing CAM workflow. Up to 10,000 times faster than traditional FEA thermal solvers, it has been independently validated by NIAR to 96.8% mean prediction accuracy and is trusted by US aerospace manufacturers for production process validation.

Distortion in WAAM and DED is caused by thermal gradients that develop as material is deposited and cools unevenly across the build geometry. Predicting and controlling distortion before printing is critical to producing parts that meet dimensional tolerances. Aibuild FETS delivers full distortion simulation as part of its thermomechanical output, returning results in seconds to minutes on standard hardware. Engineers can see exactly where distortion will take a part out of tolerance, adjust toolpath strategy accordingly, and validate the corrected build before committing to a print run. Independently validated by NIAR for aerospace applications, Aibuild FETS is the fastest distortion prediction tool available for WAAM processes.

The most reliable way to prevent failed builds in DED and WAAM is simulation before printing begins. Interpass temperature going out of range, excessive residual stress and distortion beyond tolerance are the leading causes of build failure in both processes and all three are predictable through finite element simulation. Aibuild FETS delivers full thermal, thermomechanical, distortion and residual stress simulation in seconds, giving engineers the ability to identify and design around failure risks before a single layer is deposited. Validated by NIAR and trusted by US aerospace, it is the fastest and most accessible simulation tool available for DED and WAAM process validation.

Yes. In an independent validation with Additure under the Innovate UK COMPADDITIVE project, Aibuild FETS predicted WAAM plate distortion of 1.86 mm against 1.85 mm measured, with about 0.1 mm RMS error across the part.

No. Aibuild FETS runs offline on a Windows machine with an NVIDIA GPU. No HPC, no internet connection and no cloud upload is needed, so design data stays on your hardware.

Aibuild FETS imports Marlin G-code, which most professional additive toolpath software can export, including Siemens NX and Fusion. Aibuild CAM is not required.

Not in the current version. Aibuild FETS supports DED, WAAM, AFSD, FGF and FFF on gantry and robotic systems. Laser powder bed fusion is on the roadmap.

Start a free trial.

Tell us about your process and we’ll set you up with Aibuild FETS.
